TSKTECH AUTOMATIC SOURCE CHANGEOVER MICROCONTROLLER BASED WITH CURRENT LIMIT FOR GENERATOR SUPPLY

1,180.00 Excl. of GST

It has the following functions:
• The ACCL allows unrestricted supply from mains.
• When the main supply fails and standby Generator supply is on,
— — it connects the DG power to each consumer &
— — starts monitoring its load
— — Whenever the load current exceeds the allotment (05AMP, 10AMP & 20AMP),
— — power is automatically switched off for 1 / 3/ 10 seconds, and
— — then automatically restored

Clear

Download Catalog

Description

The ACCL is a fully automatic, Microcontroller Based with Limit Current
High precision Automatic Change Over system installed in apartments, residential complexes, commercial buildings etc.

It has the following functions:
• The ACCL allows unrestricted supply from mains.
• When the main supply fails and standby Generator supply is on,
— — it connects the DG power to each consumer &
— — starts monitoring its load
— — Whenever the load current exceeds the allotment
— — — 05 AMP
— — — 10 AMP
— — — 20 AMP
— — power is automatically switched off for 1 / 3/ 10 seconds, and
— — then automatically restored
• The generator current allotment is software calibrated in AMP & sealed

Benefits and Specifications:
• Single Phase Double Pole
• Microprocessor based fully automated system
• No separate wiring required
• Assured availability of allotted current – no less, no more
• Ensures equitable rationing of generator power
• DIN channel mountable enclosures save space and make installation hassle-free
• LED indication of operational states
• Factory set and sealed calibration ensures cannot be tampered
• Single phase ACCL comes in TP MCB size (85MMx54MMx68MM)

Additional information

Weight 300 g
Dimensions 15 × 15 × 10 cm
Load Current

10AMP, 20AMP, 5AMP
